P8 LED screen panel module 256*128mm 32*16 pixels 1/4 Scan outdoor 3in1 SMD3535 RGB Full color P8 LED display panel module

P8 LED screen panel module 256*128mm 32*16 pixels 1/4 Scan outdoor 3in1 SMD3535 RGB Full color P8 LED display panel module

ZJS TECH
Accessories
P8 Outdoor SMD RGB Led Wall Panel 32*16 Pixels 256mmx128mm Waterproof Fullcolor Module Matrix Hub75 Port Pitch/mm: P8 Module size/mm: 256*128 Density of pixel(dots/m2): 15625 Pixel composition: 1R1G1B Led encapsulation: SMD3535 Resolution of module:32*16 Optimum viewing distance: 56m View angle /°: V160/H160 Average power :280 consumption/W/M2 Max power :700 consumption/W/M2 Frame frequency/Hz/S ≥60 Refresh rate Hz/S :1920 Luminance of white balance: >5000nits Driving method :1/4 scan constant current Operation of Environmental: below 30 to above 65 (Temperature/℃) Working voltage:110-220 VAC/+/-10% Grey scale/color:displaying colors≥16.7M(synchronized) Brightness adjustment: 256 levels of each color(manually),100 levels of each color(automatically) Input signal: RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc Control system Huidu/linsn/Nova(sending card,receiving cards and Hubs) Average of non-failure life >50,00h Life span >100,000h Blind dot rate <0.0001

1,000 ZMW

1,200 ZMW
Add to Wishlist

P8 LED screen panel module 256*128mm 32*16 pixels 1/4 Scan outdoor 3in1 SMD3535 RGB Full color P8 LED display panel module



About led module

  • Because of product updating fast, led module (such as the plastic housing, the Chip IC, PCB board, the screw position etc)  might be different with the picture. Pls be noted

  • Different company led module or buy them at different time, they are not compatible.

  • if need all led modules work together,buy all led modules at the same time in one order

About controller

  • We don't guarantee our led module is compatible with customer's own controller

About cables

  • buy "N" pcs led module, send "N" pcs flat cata cable +"N/2" pcs power cable
